Lab. Facilities

Lab. Facilities


Spectrometer - Chemical Analysis


 Machine Description:
                                 Spark Discharge Atomic Emission Spectrometer

 Manufacturer: SHIMADZU in Japan




Universal Testing Machine - Tensile Testing


 Machine Description: Universal Testing Machine

 Manufacturer:  Xin Sansi in Shanghai

 Range: 0~1000kN






Universal Testing Machine - Guided Bend Testing


 Machine Description: Universal Testing Machine

 Manufacturer:  HongDa in Taiwan

 Range: 0~1000kN




Universal Testing Machine - Guided Bend Testing

Operation: Both inside and outside welding shall be with 100%
radiographic inspected.

Machine:
Plant Station : TVRT B
Ray emission device: ISO VOLT 225HS;
Image receiving device: PerkinElmer flat panel detector
  (XRD  0822AP);
Save: Video Record or Static Image Capture;

Plant Station : X-Ray Film Room
Portable type: portable XXG-2505 ;
Focus size:2.5 ×2.5mm;

Capability:
Diameter (mm): no limit
Thickness(mm):8~28
Length(mm):8000~12200


Flat Panel Detector

Portable X-Ray Detector

Working Platform




Film Processing Room


 Germany PROTEC vertical industrial processing machine ;

 Marktec SMT-XW100 type film processing machine;

 Manual film processing; Intensifying Screen: before and after the lead

foil intensifying screens :0.03mm;




Drop Weight Tear Testing Machine – DWT Tesing


Machine Description:

     Drop Weight Tear Testing Machine

Manufacturer: WeiHai Testing Machine

Range: 30000J





Hardness Tester – Hardness Testing


 Machine Description:

    Vickers Hardness Tester/ Leeb Hardness Tester (Portable);

 Manufacturer:

     FUTURE-TECH in Japan (VH)/ Shi Dai Zhi Feng in Beijing (LH)

 Accuracy: ±3Hv (VH)



Charpy V-Notch Testing Machine – CNV Impact Testing


Machine Description:

    Charpy V-Notch Testing Machine

Manufacturer: Xin Sansi in ShenZhen

Range: 750J
